GD-2
Air hydraulic twin ram pit jack
2 individually controlled rams offer safe and balanced lifting
Rapid and precise air hydraulic unit with high speed ram travel
Simple modern design with control panel at ergonomical working height
Transversely sliding rams
Can be made to fit all pits due to its adjustable frame

- Adjustable frame heightFrame height is adjusted and set to the customers individual specifications
- Option rangeComprehensive option range: cross beam, support bridge etc.
- ExtensionsSupplied with 2 x 3.94 in. extensions

MADE IN DENMARK, ALWAYS.
All production of AC Hydraulic products take place in Viborg Denmark. It has done so since the founding, and it will continue to do so, following the values and goals of the Christensen family.
Specifications
Media
Manuals and Guides
Fits any lift
Our jacking beams are available in a variety of framewidths to fit any lift you may have. Our wide selection of standard or custom support arms ensure that the jacking beam and your lift work seamlessly together.
590 - 890 mm width
Distance between lifting points: 200-640 mm
850 - 1150 mm width
Distance between lifting points: 200-990 mm
1110 - 1410 mm width
Distance between lifting points: 200-1160 mm
