Air hydraulic twin ram jacking beam
2 individually controlled rams offer safe and balanced lifting
Transversely sliding rams
Can be made to fit all lifts due to its adjustable frame
Frame height is adjusted and set to the customers individual specifications
Supplied with 2 x 3.94 in extensions
- Rapid and preciseRapid and precise air hydraulic unit with high speed ram travel
- SafetyDead man’s release and safety overload valve for optimum safety
- Modern designSimple modern design with control panel at ergonomical working height
Fits any lift
Our jacking beams are available in a variety of framewidths to fit any lift you may have. Our wide selection of standard or custom mounting brackets ensure that the jacking beam and your lift work seamlessly together.
590 - 890 mm width
Distance between lifting points: 200-640 mm
850 - 1150 mm width
Distance between lifting points: 200-990 mm
1110 - 1410 mm width
Distance between lifting points: 200-1160 mm
- WARRANTYJust as our products offer high performance and quality, so does our warranty. Starting January 1st 2017 all our products are covered by a 10 year warranty on frame, chassis, and steel structures as well as a 3 year warranty on the hydraulic system (pump and cylinder). This is our way of showing you can trust our quality.
- MADE IN DENMARKWe take great pride in the fact that all products are made in Viborg, Denmark. Here, honest craftmanship is combined with a 12.000 m2 modern high-tech production plant consisting of robots, laser cutting machines and state-of-the-art CNC machinery. The result is skill, knowledge and experience married with uncompromised precision and efficiency in a product that will last a lifetime.
- ISO 9001To ensure a constantly high quality, every product is being thoroughly tested before shipment. This and many other points appear from our quality management system certified according to ISO 9001. The standard is based on seven quality management principles including a strong customer focus and continual improvement, which ensures that customers get consistent, good-quality products and services on time - every time.
